2 Layer Rogers 6006 / 6010 HF PCB High Frequency Printed Circuit Boards
Rogers PCB information:
Material:rogers6010 0.635MM
DK:10.2
Layer:2
Surface finish: immersion gold
Application:Microwave / RF field
Board thickness:0.8MM
Min lind width and space:8mil
Min hole:0.3MM
Features and benefits:
• High dielectric constant for circuit size reduction
• Low loss. Ideal for operating at X-band or below
• Low Z-axis expansion for RT/ duroid 6010LM. Provides reliable
plated through holes in multilayer boards
• Low moisture absorption for RT/duroid 6010LM. Reduces effects of moisture on electrical loss
• Tight and thickness control for repeatable circuit performance
Rogers 6006 / 6010 information:
RT/duroid 6006/6010LM microwave laminates are ceramic-
PTFE composites designed for electronic and microwave circuit
applications requiring a high dielectric constant. RT/duroid 6006
laminate is available with a dielectric constant value of 6.15 and
RT/duroid 6010LM laminate has a dielectric constant of 10.2.
RT/duroid 6006/6010LM microwave laminates feature ease of fabrication
and stability in use. They have tight dielectric constant and thickness
control, low moisture absorption, and good thermal mechanical stability.
Standard tolerance dielectric thicknesses of 0.010”, 0.025”, 0.050”, 0.075”,
and 0.100” (0.254, 0.635, 1.270, 1.905, 2.54 mm) are available. When
ordering RT/duroid 6006 and RT/duroid 6010LM laminates, it is important
to specify dielectric thickness and weight of copper foil required.
FAQ
Q1.What is needed for quotation?
A: PCB : Quantity, Gerber file and Technic requirements(material, surface finish treatment, copper thickness, board thickness)
PCBA: PCB information, BOM, (Testing documents)
Q2. What file formats do you accept for production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security.
We protect the intellectual property for our customers in the whole process.
All documents from customers are never shared with any third parties.
Q4. MOQ?
There is no MOQ. We are able to handle Small as well as large volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods.
Please let us know if you need us to quote you the shipping cost.
Q6. Do you accept process materials supplied by clients?
A: Yes, we can provide component source, and we also accept component from client..
